Detector type

Uncooled focal plane

wavelength coverage

8~14μm

Pixel number

384×288/640×480

Pixel size

25μm

FPS

25Hz

Temperature measurement performance and image performance

Temperature measuring range

20~45℃

Temperature measurement accuracy

0.5℃

Thermal sensitivity (NETD)

viewing angle

36o×27o

angular resolution

1.7mrad

Focusing mode

Electric/manual, the electric lens supports autofocus, and displays the image sharpness in real time to assist manual focusing.

Clear imaging range

0.3m~∞, the near-end distance of some models of lenses is slightly larger.

Temperature measuring mode

Support global high and low temperature tracking, global average temperature, point, line, rectangle, circle, ellipse, polygon and other temperature measuring modes, and add up to 20 temperature measuring objects. All temperature measuring objects can independently set alarm threshold range, sampling period and draw historical temperature curves.

High and low temperature alarm

The control terminal gives an audible and visual alarm and records the log. When the alarm is triggered, the temperature data and image snapshot can be automatically stored. Camera-side alarm output level indication

Auxiliary temperature analysis

Relative temperature analysis, temperature histogram analysis, historical temperature curve, online temperature curve.

Data storage

Report generation

Word format with content selection wizard

Temperature data stream playback

The playback is time stamped, and the playback speed can be adjusted, frozen and played circularly. When playing, the image can be processed and super-resolution images can be output.

running log

Automatic recording, automatic saving

network connections

data interface

100M Ethernet, supporting TCP, UDP, IP, DHCP, ARP, ICMP and other protocols.

environmental parameter

Working temperature

-30~60℃

storage temperature

-40~80℃

Enclosure protection grade

IP54, optional IP65

Electrical interface

Analog video

NTSC/PAL with display of maximum temperature, minimum temperature and average temperature, BNC interface.

Yuntai control

Pan/tilt can be controlled through computer serial port or camera serial port, with built-in PELCO-D/P protocol verification.

Power Supply

The power adapter inputs AC 100 ~240V, outputs DC 12V/1.25A, and uses aviation plug with self-locking.

power consumption

2.0W

Physical attribute

measure

110mm(L)×70mm(W)×68mm(H) (excluding lens)

weight

0.46kg (excluding lens)

Installation interface

UNC 1/4-20 standard tripod interface, M3 threaded interface
