Detector

Uncooled focal plane array

Pixel number

384×288

Pixel size

17μm×17μm

Response band

8~14μm

Imaging performance

Sensitivity (NETD)

Frame frequency

50Hz /60Hz

viewing angle

10.6°×8.0°

MRAD (spatial resolution)

0.68 mrad

Optical magnification

1.9

Electron magnification

2x/PIP/4x

distance of exit pupil

60mm

Diopter adjustment range

±5

Analog video output

PAL system or NTSC system

indicator

0.39 inch, OLED,1024×768

Image mode

Black heat mode, white heat mode, red heat mode

Detection distance (vehicle) 1.4mx4.0m

1800m

Recognition distance (vehicle)

600m

Detection distance (person): 1.8mx0.5m

1350m

Recognition distance (person)

450m

System function

Hot spot tracking

support

videotape

support

Wifi

Support frequency 2.4

GPS

support

save

Support, (* * ******32GB)

endurance

Can run for 6 hours.

take a picture

support

White light illumination

support

Digital zoom

support

Laser indication

support

Circumstance parameter

Working temperature

-25℃～+50℃

storage temperature

-40℃～+70℃

the protection grades

IP67

Impact vibration

1000g/ms

Physical parameter number

Chi Cun

176mm (length) x61mm (width) x67mm (height)

Heavy weight

About 380g
