Image parameter

Detector

Vanadium oxide uncooled focal plane array

Pixel number

384×288／640×512

Pixel size

17μm×17μm

Response band

7.5～13.5um

Optical performance

Focal distance

f=15mm（F#1.0）

Visual field angle

24.9°*18.7°

Imaging performance

N E T D

≤45mK@25℃

Image frame rate

25Hz

analog output

PAL system or NTSC system

image processing

Digital image detail enhancement (DDE)

start time

≤5s

Power source and interface

supply voltage

Standard DC 12V (DC 5～24V optional)

Power consumption

≤2W

communication interface

RS232/RS485

Connector type

BNC, standard 6m cable

Circumstance parameter

Working temperature

-40℃ ～ +60℃

Storage temperature

-45℃ ～ +70℃

Humidity

Work and storage at 10% to 95%, non-condensing.

Seal

Sealed shell

Impact experiment

15g, 11ms±2ms half sine wave

Vibration experiment

5～500Hz， 0.01g2/Hz

Physical particularity

Appearance size

65mm×65mm×53mm

Heavy weight

≤330g (excluding connector)
