Image parameter

Detector

HgCdTe focal plane

Pixel number

320×256

Pixel size

30μm×30μm

Response band

3.7 μ m to 4.8 μ m or 7.7 μ m to 11.0 μ m.

Bad pixel number

＜1%

filling factor

＞80%

Refrigeration

Stirling refrigeration

Imaging performance

N E T D

≤15mK@25℃（F#2）

Frame frequency

50Hz, 100Hz, 200Hz (digital video)

analog output

PAL system or NTSC system

Extended storage

2GB or 4GB/8G/16G is optional.

start time

≤7mins

Control work energy

Digital video interface

2-wire LVDS (standard), Ethernet, USB (optional)

Brightness/contrast

Automatic/manual

Electron zoom

2 times, 4 times

Polarity

White/black heat

Cross division

Show/Blank

Electric source system

supply voltage

Standard DC+24V (DC8 ~ 42V optional)

Power consumption

≤18W (stable operation at room temperature ≤12W)

Circumstance parameter

Operating temperature:

-30℃ ~+60℃ (-40℃ ~+60℃ optional)

storage temperature

-40℃～+80℃

Impact experiment

30g, 11ms±2ms half sine wave

Vibration experiment

5～500Hz， 0.01g2/Hz

Physical particularity

Overall dimensions:

≤140.5mm×69mm×89mm

Weight:

≤650g
