explorer

Detector type

Uncooled focal plane

wavelength coverage

8~14μm

Pixel number

384×288/640×480

Pixel size

17μm

FPS

50Hz

Temperature measurement performance and image performance

Temperature measuring range

-20℃-300℃

Temperature measurement accuracy

2℃ or 2%

Thermal sensitivity (NETD)

viewing angle

26°×20°

angular resolution

1.13 mard/0.68 mard

Clear imaging range

0.3m~∞

Temperature measuring mode

Support global high and low temperature tracking, global average temperature, point, line, rectangle, circle, ellipse, polygon and other temperature measuring modes, and add up to 20 temperature measuring objects. All temperature measuring objects can independently set alarm threshold range, sampling period and draw historical temperature curves.

High and low temperature alarm

The control terminal gives an audible and visual alarm and records the log. When the alarm is triggered, the temperature data and image snapshot can be automatically stored. Camera-side alarm output level indication

Electron double focus

2X, 4X, full screen

Data storage

Report generation

Word format with content selection wizard

Temperature data stream playback

The playback is time stamped, and the playback speed can be adjusted, frozen and played circularly. When playing, the image can be processed and super-resolution images can be output.

running log

Automatic recording, automatic saving

network connections

data interface

100M Ethernet, supporting TCP, UDP, IP, DHCP, ARP, ICMP and other protocols.

IP allocation

Dynamic IP and static IP, and the control terminal is integrated with DHCP Server.

environmental parameter

Working temperature

-30~60℃

storage temperature

-40~80℃

Shell protection

IP54

Electrical interface

serial port

RS232, which can forward the control instruction of PTZ.

Yuntai control

Pan/tilt can be controlled through computer serial port or camera serial port, with built-in PELCO-D/P protocol verification.

Power Supply

The power adapter inputs AC 100 ~240V, outputs DC 12V/1.25A, and uses aviation plug with self-locking.

power consumption

2.0W

Physical attribute

measure

64mm(L)×64mm(W)×62mm(H) (excluding lens)

weight

0.28kg (excluding lens)

Installation interface

1/4-20 standard tripod interface
